SECTION 2Operation

2-6 6110 Hand-Held Computer User’s Guide

In External Source

When your battery pack is placed in a multipack or single

pack charger, the dock will indicate the charge state (red =

charging; green = fully charged; blinking red = bad battery

or bad connection). Figure 2-3 shows a multipack charger

and Figure 2-4 shows a single pack charger.

Figure 2-3

Multipack Charger

Battery Pack Compartments (8)

Charge Indicator LED (one per compartment)

Power Cord Connector

Fuse
